1U Modular Rack

was €121.38 Special Price €109.48 €92.00
1U Modular Rack built from a 15 mm thick tough birch plywood, with 450 mm usable depth. The stackable rubber feet and cutout for cable crossing make it easy for you to stack and connect them together. Customise it as you need by choosing from the options below:
Availability: Dispatches in 8-12 business days
SKU
1u-modular-rack

Our Modular Racks system is built from a 15 mm thick tough birch plywood and provides a 450 mm usable depth. The stackable rubber feet and cutout for cable crossing make it easy for you to stack and connect them together. The optional back rack rail, front lid and back lid give you the freedom to configure a system completely adapted to your needs.

Transporting them is easy with the help of our FlexiTrans 1200 / FlexiTrans 800 / FlexiTrans 600 flight cases.

SPECIFICATIONS

  • 450 mm Usable Depth
  • Built from 15 mm Thick Birch Plywood
  • Heavy Duty Infinite Rack Rail with Fittings and Screws Included
  • 4 Rubber Feet for Stacking

EXTRA OPTIONS

  • Rack Rail at the Back
  • Front & Back Lid
  • Custom Engraving

DIMENSIONS & WEIGHT

(rubber feet included)

External Dimensions (WxDxH): 524 x 535 x 87 mm

Weight: 5.1 kg

Modular Racks Usable Depth

450 MM USABLE DEPTH

You can install equipments with a depth of up to 450 mm. Do note that the usable depth is measured from the face of the front rack rail to the back of the rack. If you install a back lid, the usable depth decreases to 430 mm.

15 MM THICK PLYWOOD

Our modular racks are built from a 15 mm thick tough birch plywood, strong enough to hold and protect even the heaviest equipments.
Modular Racks Plywood
Stackable Modular Racks

EASY TO STACK

Due to the cutouts on top and the rubber feet on the bottom that fit perfectly inside the cutouts, it's easy to stack our modular racks on top of each other.

CABLE CROSSING

The cable crossing cutouts let you connect the equipments without worrying about loose cables and let you use the racks with the back lid installed.
Modular Racks Cable Crossing
Modular Racks Back Rack Rail

OPTIONAL RACK RAIL AT THE BACK

Optionally, add a rack rail at the back. The standard distance between the front and the back rack rails is 380 mm. If you need the back rack rail mounted at another distance, please let us know in the Order Comments section available at Checkout.

OPTIONAL FRONT LID

If you need a front lid to protect your equipments, you can add one to your cart here: Modular rack front lid. It comes with 2 push latches and a handle cutout.
Modular Racks Front Lid
Modular Racks Back Lid

OPTIONAL BACK LID

Optionally, you can add a back lid to your cart here: Modular rack back lid. It comes with 2 sliding latches.

RACK ENGRAVING

Many of our images show flight cases engraved with brand and model or client logo. This is not included, our standard flight cases come without engraving. If you would like your flight case to be engraved with your company logo, please add this option to the cart. You will receive an email from us requesting a vector file with your logo. If you don't have a vector file, we can vectorise it for you for an extra fee. You will be informed on the additional price for vectorising your logo, as this differs depending on the complexity. If you only want the brand or model of the equipment engraved then simply add the engraving option to the cart and we will manage the rest.
